1mm Twin Core Pure Copper Electrical Wire - 52 Strands - 50m Roll
Remaining 50 only
Premium 1mm dual-core flexible wire with 52 strands of 100% pure copper for lighting installations. Features flame-retardant PVC insulation compliant with IEC standards for optimal safety. Quality guaranteed by Grand City Media Company.
more informationSAR 70.00
SAR 100.00
Discount 30%
+
Earn loyalty points with this purchase
Rewardsproduct sku
03175
Weight
1.42 kg
share product
product description
Dual-core electrical wire featuring a 1mm conductor cross-section and a flexible structure composed of 52 fine copper strands, each with a diameter of 0.16mm. The conductor is engineered from 100% pure copper to minimize electrical resistance, enclosed in a premium polyvinyl chloride (PVC) insulation layer that resists flame propagation and sustains temperatures up to 70°C. Designed for a rated voltage operating range of 300/500V, this cable supports a continuous current rating between 10A and 13A, strictly complying with the International Electrotechnical Commission (IEC) standards for lighting and electrical installations.
Technical Specifications Table
| Property / Feature | Technical Specifications |
| Product Description | Pure flexible copper wire for lighting and electrical installations |
| Conductor Type | 100% Pure Copper |
| Total Roll Length | 50 Meters |
| Number of Cores / Pathways | 2 Cores (Double Core) |
| Conductor Cross-Section | 1mm (1mm) |
| Conductor Structure / Core | Flexible Stranded Wire |
| Number of Copper Strands | 52 Strands (facilitates seamless pulling through narrow conduits) |
| Strand Diameter | 0.16mm |
| Insulation Material | High-grade Polyvinyl Chloride (PVC), weather-resistant |
| Rated Operating Voltage | 300 / 500 Volts |
| Current Carrying Capacity | 10 - 13 Amps maximum (subject to installation conditions) |
| Maximum Total Power (Wattage) | 2200 - 2800 Watts (at 220V voltage) |
| Maximum Operating Temperature | Up to 70°C |
| Flexibility Classification | Class 5 (optimized for effortless routing and pulling) |
| Total Gross Weight | 1.42 kg |
Technical Features
-
100% Pure Copper Conductor: Guarantees maximum current transmission efficiency and reduces resistance to ensure continuous power stability.
-
Excellent Thermal Stability: The engineered 52-strand configuration withstands demanding operating conditions and continuous loads effectively.
-
Flame-Retardant Durable Insulation: The robust PVC protective layer prevents flame propagation, ensuring a secure and sustainable environment.
-
International Standards Compliance: Fully compliant with the International Electrotechnical Commission (IEC) specifications approved for commercial and corporate projects.
-
High Engineering Flexibility: Highly flexible strands allow rapid and effortless pulling and routing through tight conduits and flexible hoses.
